Perforated filter tube,Perforated filter tube factory-Wuzhou Kingda Wire Cloth Co. Ltd

Perforated filter tube

Category:Perforated Metal Mesh
Material:AISI 304,304l,316,316L;woven wire mesh
Properties:perforated metal mesh
Application:filtration and separation in the industry of oil

tags:
Perforated filter tube,Perforated filter,Perforated tube,

Inquiry now

Send email

We highly appreciate your feedback. TEL: 0086-10-68220585 E-mail: sales@kingdamesh.com

Mesh Description
Mesh Specification
Relevant Picture
Recommend Products

Perforated filter tube
1. Material of Perforated filter tube:
Perforated filter tube can be made of AISI 304, 304l, 316, 316L; woven wire mesh, perforated metal sheet, welded wire mesh or brass wire mesh, aluminum mesh nickel-plated copper and so on.
2. Application of perforated filter tube:
Perforated filter tube is widely used for filtration and separation in the industry of oil, chemistry industries, automobile industries, medicine industries, food industries, water treatment petroleum industries, pharmacy industries, agriculture filteration equipment, etc.
3. Features of perforated filter tube:
Acid and alkali resistance, heat –resistant, hard wearing, long lasting easy to wash for reuse, lat and smooth surface. Layers are removable, single layer can be independent use.
4. Weave characteristics:
Stamping, outspread, Divided into: mesh, steel, aluminum, punching sieve net, loudspeaker meshes board, etc

Perforated filter tube

5. Reference specifications of perforated filter tube:

Mesh/inch	Wire Diameter/mm	Aperture/mm	Mesh/inch	Wire Diameter/mm	Aperture/mm
2mesh	1.80	10.90	60mesh	0.15	0.273
3mesh	1.60	6.866	70mesh	0.14	0.223
4mesh	1.20	5.15	80mesh	0.12	0.198
5mesh	0.91	4.17	90mesh	0.11	0.172
6mesh	0.80	3.433	100mesh	0.10	0.154
8mesh	0.60	2.575	120mesh	0.08	0.132
10mesh	0.55	1.990	140mesh	0.07	0.111
12mesh	0.50	1.616	150mesh	0.065	0.104
14mesh	0.45	1.362	160mesh	0.065	0.094
16mesh	0.40	1.188	180mesh	0.053	0.088
18mesh	0.35	1.060	200mesh	0.053	0.074
20mesh	0.30	0.970	250mesh	0.04	0.061
26mesh	0.28	0.696	300mesh	0.035	0.049
30mesh	0.25	0.596	325mesh	0.03	0.048
40mesh	0.21	0.425	350mesh	0.03	0.042
50mesh	0.19	0.318	400mesh	0.25	0.0385

We also can provide other specification according to the clients' requirements. Meanwhile, we accept the business of processing supply material.
